A powerful design.

Twelve years after starting the four-stroke revolution, with its award winning DF70 and DF60 outboards, Suzuki has reinvented the category again with the DF90A. The first of Suzuki’s new generation of four-strokes, the DF90A is a showcase of advancements and achievements – like digital sequential electronic fuel injection, a powerful 2.59:1 final drive ratio, and a zero-maintenance self-adjusting time chain. All of this comes in addition to Suzuki’s Lean Burn Control System, and newer models also sport the optional Suzuki Troll Mode System.



See Product Brochure here.

DF75A_QTN_Single_MV620_Action_1

Features

  • 1
  • 2
DF 75 A

Be in the know

The DF90A hosts digital sequential electronic fuel injection, meaning it reads the electronic control unit monitors throttle setting, engine RPM, cylinder wall and air-intake temperature and atmospheric pressure all at once. All of these considerations cause the fuel injection to enter the combustion chamber at the most optimal opportunity. The benefits are smoother and faster acceleration, crisp throttle response and quick, reliable starting, no matter what the temperature is.

Feature_TrollMode

Don’t scare the fish

Glide into your favorite fishing honeyhole with Suzuki’s Troll Mode System. The engine’s revs can be adjusted in 50 rpm intervals by simply pressing the Troll Mode control switch from idle up to 1200 rpm, giving you control over your wake and speed.

Specifications

MODEL
DF90A
Body Color
Pearl Nebular Black or Cool White
Recommended Transom Height (inches)
L: 20 X: 25
Starting System
Electric
Weight LBS
L: 343 X: 352
Engine Type
DOHC 16-Valve
Fuel Delivery System
Multi Point Sequential Electronic Fuel Injection
No. Of Cylinders
4
Piston Displacement inches (cc)
91.7 (1502)
Bore X Stroke Inches (mm)
3.00 x 3.30 (75 x 85)
Maximum Output HP
90
Operating Range (RPM)
5300 - 6300
Steering
Remote (Tiller Kit Optional)
Choke
N/A
Oil Pan Capacity quarts (liter)
4.2 (4.0)
Ignition System
Solid State Direct Ignition
Alternator
12V 27A
Trim Position
Power Trim and Tilt
Gear Ratio
2.59:1
Standard Propeller
Optional See Dealer
Propeller Selection
13 - 23
Additional Information:
