Light on weight. Light on compromise.

The result of a complete redesign that strove to create the lightest parts possible without compromising integrity, our engineers have successfully crafted an outboard that, even when configured with a power tilt system, still weighs less than any other outboard in the four stroke 14.7kW (20PS) class. Beyond being ultra-light, the DF20A EFI is also among the most technologically advanced portable outboard motors on the market, featuring Suzuki’s proven Lean Burn Control System and Battery-Less Electronic Fuel Injection.



See Product Brochure here.

DF20_Lifestyle

Features

  • 1
DF20A EFI

TWENTY HORSES. AT YOUR COMMAND.

Our DF20A represents a unique leap forward in the way that power is converted into performance. Through extensive testing, we have engineered this small footprint motor to make the most of every ounce of horsepower. Beyond being ultra-light, the DF20A EFI is also among the most technologically advanced portable outboard motors on the market.

Specifications

MODEL
DF20A
Recommended Transom Height (inches)
S: 15" L: 20"
Starting System
S 15" Manual and Electric / L 20" Electric
Weight lbs
S Manual:97 lbs S Electric:105 lbs / L Electric:108 lbs
Engine Type
SOHC 4-Valve
Fuel Delivery System
Electronic Fuel Injection with Lean Burn
No. Of Cylinders
2
Piston Displacement inches (cc)
20.0 (327)
Bore X Stroke Inches (mm)
2.38 x 2.24 (60.4 x 57)
Maximum Output HP
15
Operating Range (RPM)
5000 - 6000
Steering
Tiller
Choke
N/A - Suzuki EFI
Oil Pan Capacity quarts (liter)
1.06 (1.0)
Ignition System
Digital CDI
Alternator
Manual 12V 6A / Electric 12V 12A
Trim Position
5 Tilt Pin Positions and 2 Shallow Water Drive Settings - Option Power Tilt
Gear Ratio
2.08:1
Standard Propeller
3 x 9.25 x 9
Propeller Selection
7 - 11
