Tried and true.
The DF225T is a mechanically controlled 3.6 liter V-6 model designed for compatibility with Suzuki’s CAN Bus system, which supports integration for rigging as well as features such as an easy start system, automatic trim, keyless starting, and troll mode. This V-6 engine includes dual overhead cam 24-valve powerheads, variable valve timing, multi-stage induction, updated cowling, and louvers to support performance and efficiency.
Features
- 1
Built to run.
The DF225 is capable of producing approximately 38 Amps of power, ensuring reliable operation for your vessel even at engine speeds as low as 1,000 rpm. This output is sufficient to meet all onboard electrical requirements under various conditions.
Specifications
MODEL
DF225T
Body Color
Pearl Nebular Black or White
Recommended Transom Height (inches)
X:25
Starting System
Electric
Weight LBS
X:606
Engine Type
DOHC 24-Valve
Fuel Delivery System
Multi Point Sequential Electronic Fuel Injection
No. Of Cylinders
V6 (55°)
Piston Displacement inches (cc)
220.5 (3614)
Bore X Stroke Inches (mm)
3.74 x 3.35 (95 x 85)
Maximum Output HP
225
Operating Range (RPM)
5000-6000
Steering
Remote
Choke
N/A
Oil Pan Capacity quarts (liter)
8.5 (8.0)
Ignition System
Solid State Direct Ignition
System Output
12V 54A
Trim Position
Power Trim and Tilt
Gear Ratio
2.29:1
Standard Propeller
Optional See Dealer
Propeller Selection
17 - 27.5
Additional Information:
